Product Introduction：
ZY-XCTD500 Wire Stiffness Tester (Material Bending Performance Tester) is a professional equipment mainly used to evaluate the stiffness and rebound force of flexible materials (such as wires, cables, metal wires, cables, etc.), as well as their ability to resist bending deformation; The longitudinal and transverse directions, tension magnitude, testing speed, and bending angle of the sample can be set according to the experimental requirements.
working principle：
Measure the force or moment required to bend a clamped specimen at one end to a 15 degree angle under specified conditions, expressed in gf. cm (mN). If the specimen is too stiff or the specimen fractures after bending to a 15 degree angle, the bent specimen can be adjusted to a 7.5 degree angle. Multiply the measurement result by 2 to obtain an approximate value, but it should be noted in the report.
Product Features：
1. The new generation of ecological intelligent operating system improves the response speed of instruments and calculates data accurately and quickly
2. 7.5 ° and 15 ° stiffness tests (unidirectional testing angle adjustable from 1 to 30 °). Between arbitrary settings)
3. The change in testing angle is fully automatically controlled by the motor to improve testing efficiency
4. Adjustable testing time
5. Automatic reset, overload protection
6. Equipped with functions such as measurement statistics and printing, it facilitates users to conduct experimental operations and view data;
Technical Specifications:
1.Sample size: (70~200) mm
2. Actual measurement range: (1~50) mm
3. Test spacing: Adjustable in 1mm increments (5mm, 10mm, 15mm, 20mm, 25mm, 30mm, 40mm, 50mm)
4. Span accuracy: ±0.1 mm
5. Measurement range: (0~10000 mN)
6. Sensor: ±0.1% sensing accuracy
7. Resolution: 0.01 mN
8. Bending angle: Unidirectional test angle adjustable from 1~30º
9. Multifunctional measurement: Forward and reverse stiffness
10. Angular velocity control: Adjustable from 0.5~5/sec
11. Angle accuracy: ±0.1
12. Thickness measurement: (0.01~5.0) mm
13. Bending duration: (2~30s)
14. Sample fixture: Manual clamping with automatic reset after testing
15. Clamping method: Unlimited support for non-destructive continuous clamping
16. Operation interface: 7-inch touchscreen or button operation
17. Signal output: Standard computer signal output (optional computer connection)
18. Print output: Modular integrated thermal printer
11. Dimensions: 400mm*400mm*260mm (actual dimensions apply)
20. Net weight: 26kg (actual weight applies)
